R256F

All our motors are manufactured with the highest standard. Our stringent quality assurance process guarantees peak performance for every motor from day one.

Motor Details

Performance Chart
Technical Specs
Model : R256F-CT-9Z400
Voltage : 12V
No Load Max Efficiency Max Output Stall
Current (A) 0.013 0.057 0.133 0.253
Speed (rpm) 2812 2292 1406 N/A
Torque (g.cm) N/A 16.9 45.6 91.2
Efficiency (%) N/A 57.6 N/A N/A
Output (W) N/A N/A 0.66 N/A

Model : R256F-CT-9Z400
Voltage : 12V
No Load Max Efficiency Max Output Stall
Current (A) 0.013 0.057 0.133 0.253
Speed (rpm) 2812 2292 1406 N/A
Torque (g.cm) N/A 16.9 45.6 91.2
Efficiency (%) N/A 57.6 N/A N/A
Output (W) N/A N/A 0.66 N/A

Model : R256F-CT-10340
Voltage : 12V
No Load Max Efficiency Max Output Stall
Current (A) 0.016 0.073 0.175 0.334
Speed (rpm) 3356 2753 1678 N/A
Torque (g.cm) N/A 18.8 52.4 104.8
Efficiency (%) N/A 60.6 N/A N/A
Output (W) N/A N/A 0.90 N/A

Model : R256F-CT-10340
Voltage : 12V
No Load Max Efficiency Max Output Stall
Current (A) 0.016 0.073 0.175 0.334
Speed (rpm) 3356 2753 1678 N/A
Torque (g.cm) N/A 18.8 52.4 104.8
Efficiency (%) N/A 60.6 N/A N/A
Output (W) N/A N/A 0.90 N/A

Model : R256F-CT-10380
Voltage : 4.5V
No Load Max Efficiency Max Output Stall
Current (A) 0.014 0.064 0.155 0.296
Speed (rpm) 3023 2483 1512 N/A
Torque (g.cm) N/A 18.6 52.0 103.9
Efficiency (%) N/A 61.2 N/A N/A
Output (W) N/A N/A 0.81 N/A
Model : R256F-CT-10380
Voltage : 4.5V
No Load Max Efficiency Max Output Stall
Current (A) 0.014 0.064 0.155 0.296
Speed (rpm) 3023 2483 1512 N/A
Torque (g.cm) N/A 18.6 52.0 103.9
Efficiency (%) N/A 61.2 N/A N/A
Output (W) N/A N/A 0.81 N/A
