R500F

All our motors are manufactured with the highest standard. Our stringent quality assurance process guarantees peak performance for every motor from day one.

Motor Details

Model : R500F-CN-12520
Voltage : 6.0V
No Load Max Efficiency Max Output Stall
Current (A) 0.020 0.081 0.174 0.327
Speed (rpm) 2663 2135 1332 N/A
Torque (g.cm) N/A 12.0 30.3 60.5
Efficiency (%) N/A 54.1 N/A N/A
Output (W) N/A N/A 0.41 N/A
Model : R500F-CN-12520
Voltage : 6.0V
No Load Max Efficiency Max Output Stall
Current (A) 0.020 0.081 0.174 0.327
Speed (rpm) 2663 2135 1332 N/A
Torque (g.cm) N/A 12.0 30.3 60.5
Efficiency (%) N/A 54.1 N/A N/A
Output (W) N/A N/A 0.41 N/A
Model : R500F-CN-16260
Voltage : 4.5V
No Load Max Efficiency Max Output Stall
Current (A) 0.037 0.179 0.450 0.862
Speed (rpm) 4174 3458 2087 N/A
Torque (g.cm) N/A 13.4 39.2 78.3
Efficiency (%) N/A 59.3 N/A N/A
Output (W) N/A N/A 0.84 N/A
Model : R500F-CN-16260
Voltage : 4.5V
No Load Max Efficiency Max Output Stall
Current (A) 0.037 0.179 0.450 0.862
Speed (rpm) 4174 3458 2087 N/A
Torque (g.cm) N/A 13.4 39.2 78.3
Efficiency (%) N/A 59.3 N/A N/A
Output (W) N/A N/A 0.84 N/A
Model : R500F-CN-22150
Voltage : 6V
No Load Max Efficiency Max Output Stall
Current (A) 0.084 0.511 1.594 3.104
Speed (rpm) 9766 8386 4883 N/A
Torque (g.cm) N/A 24.0 84.8 169.6
Efficiency (%) N/A 67.3 N/A N/A
Output (W) N/A N/A 4.25 N/A
Model : R500F-CN-22150
Voltage : 6V
No Load Max Efficiency Max Output Stall
Current (A) 0.084 0.511 1.594 3.104
Speed (rpm) 9766 8386 4883 N/A
Torque (g.cm) N/A 24.0 84.8 169.6
Efficiency (%) N/A 67.3 N/A N/A
Output (W) N/A N/A 4.25 N/A
